10L Large Flow Medical Oxygen Concentrator OLV-10 With CE Approved

Model Number: OLV-10

Product highlight: Produce oxygen+atomizing, guaranteed oxygen technology, Available for two people use

Product features: 0-10L oxygen flow adjustable, Wheels with brake, 2 years warranty, CE ISO approved

Application: Hospital and home medical care

Customization: OEM and ODM services are available according to your needs, ideas and samples.


For business OEM/ODM bulk sales service, please inquire us right now


Working principle of high concentration oxygen concentrator

Working principle of high concentration oxygen concentrator


The air compressor removes oil, dust and other solid impurities and most of the gaseous water through the pretreatment system, and enters the adsorption tower equipped with molecular sieve. The nitrogen, carbon dioxide, and water vapor in the air are adsorbed, and the cycle cycle of decompression and desorption, Make compressed air alternately enter the adsorption tower to achieve separation, thereby continuously producing high-concentration oxygen

Product parameter

Product parameter


10L Large Flow Medical Oxygen Concentrator With CE Approved
ModelOLV-10
Oxygen flow0-10L/min
Oxygen concentration≥ 93%±3%
Power supply220V 士 22V, 50Hz 士 1Hz/110V 土 11V, 60Hz 士 1Hz
Output pressure20Kpa-60Kpa

Power Consumption

800VA
Sound level50dB
Net Weight20KG
Dimension(MM)344 X 306 X 565(mm)
Working SystemContinuous flow
Atomization quantity≥0.15ml/min (Only modes with atomization function)


Feature

France imported CECA molecular sieve

High oxygen purity 93%±3%

Long life span more than 18000 hours

2 years warranty

Large LED display

Voice function

Wheels with brake

CE ISO approved

10L Large Flow Medical Oxygen Concentrator OLV-10 With CE Approved
10L Large Flow Medical Oxygen Concentrator OLV-10 With CE Approved

48 Hours

Continuous Operation

2 Patients

Provide Oxygen For 2 Patients

90-96%

High Oxygen Concentration

0-10L

Dual Flow Oxygen Concentrator

Request a quote

Annual sales of 80000 units

Olive has been focusing on the production and research and development of medical oxygen concentrators for a long time, and has continuously broken through the key areas of oxygen concentrators and obtained a number of patents and domestic and foreign recognitions.
