Home > Products > Olive Oxygen Concentrator > Quiet Portable Oxygen Concentrator > Portable Oxygen Concentrator With Battery

OLV-B1 Portable Oxygen Concentrator With Battery

Model Number: OLV-B1

Product highlight: Three power supplies:220V/110V, 12V(Car use), Rechargeable battery

Product features: Adjustable continuous flow, Rechageable battery, Low Noise

Application: suitable for the use of health care

Customization: OEM and ODM services are available according to your needs, ideas and samples.


For business OEM/ODM bulk sales service, please inquire us right now


Working principle of high concentration oxygen concentrator

Working principle of high concentration oxygen concentrator


The air compressor removes oil, dust and other solid impurities and most of the gaseous water through the pretreatment system, and enters the adsorption tower equipped with molecular sieve. The nitrogen, carbon dioxide, and water vapor in the air are adsorbed, and the cycle cycle of decompression and desorption, Make compressed air alternately enter the adsorption tower to achieve separation, thereby continuously producing high-concentration oxygen

Product parameter

Product parameter


Model NoOLV-B1
Flow Rate0-5L/min
Input Power90W
Purity Oxygen≥90%±3%(1LPM)
Power SupplyAC220V±22V, 50Hz±1Hz / AC110V±15V, 60Hz±1Hz
DC12V
Rechargeable Battery 10000mAh(1H), 13000mAh(1.5H)
Output pressure20kPa~60kPa
NoiseLess than 40db
Net Weight5kg
Dimension:245*181*365 (mm)
Warranty1 years
Battery Duration60 mins or 90 mins
Battery Rechage Time4 hours recharge to achieve 90% capacity

Feature

Oxygen flow: continuous flow, 0-5L/min adjustable

Light weight: 5Kg

Three power supplies:220V/110V, 12V(Car use), Rechargeable Lithium-ion Battery

Low noise: less than 40dB

Anion function

Integrated designing

Good quality material

OLV-B1 Portable Oxygen Concentrator With Battery
OLV-B1 Portable Oxygen Concentrator With Battery

48 Hours

Continuous Operation

Low Noise

Less Than 45 dB

90-96%

High Oxygen Concentration

1-5L

Oxygen Flow Adjustable

Request a quote

Annual sales of 80000 units

Olive has been focusing on the production and research and development of medical oxygen concentrators for a long time, and has continuously broken through the key areas of oxygen concentrators and obtained a number of patents and domestic and foreign recognitions.

Annual sales of 80,000 units
